Product Name: Tungsten Carbide Ball Nose Milling Bits For 65HRC Work Material
Product Parameters:
1. Brand name: Tantivy, or OEM
2. Grade: 65HRC
3. Raw material: Sandvik carbide H10F from Sweden
4. Grain Size: Super micro grain 0.4μ
5. Type: Ball head, Tungsten carbide milling bits
6. Flute: 2 Flute
7. Helix angle: 30°
8. Diameter: 1mm-25mm
9. Overall Length: 50-100mm
10. Coating/Coverage: Nano-B, Blue color
11. Cobalt: 10%
12. Tolerance: <8mm:0.005-0.01, >8mm:0.01-0.02
13. HRC: for upto 65HRC work material
14. Controlling mode: High speed milling machines
15. Work material: Alloy steel, Tool steel, Carbon steel, Cast Iron, Stainless steel and High hardness steel after heat treatment
Main Features:
Made of high hardness raw carbide material, high durable and strength. Special for high speed and high hardness processing, with Nano copper coating on the flute, it can cut 65HRC work material after heat treatment, from roughing to finishing. Also it will reduce the times of tool changes and shaking in the processing, save production time and improve efficiency.
Specifications:
|
Part Number |
R |
Shank/mm |
Flute Length/mm |
Overall Length/mm |
Flute |
|
BNM04010050-650 |
R0.5 |
4 |
2 |
50 |
2 |
|
BNM04015050-650 |
R0.75 |
4 |
3 |
50 |
2 |
|
BNM04020050-650 |
R1.0 |
4 |
4 |
50 |
2 |
|
BNM04025050-650 |
R1.25 |
4 |
5 |
50 |
2 |
|
BNM04030050-650 |
R1.5 |
4 |
6 |
50 |
2 |
|
BNM03030050-650 |
R1.5 |
3 |
6 |
50 |
2 |
|
BNM04035050-650 |
R1.75 |
4 |
7 |
50 |
2 |
|
BNM04040050-650 |
R2.0 |
4 |
8 |
50 |
2 |
|
BNM06050050-650 |
R2.5 |
6 |
10 |
50 |
2 |
|
BNM05050050-650 |
R2.5 |
5 |
10 |
50 |
2 |
|
BNM06060050-650 |
R3.0 |
6 |
12 |
50 |
2 |
|
BNM08080060-650 |
R4.0 |
8 |
26 |
60 |
2 |
|
BNM10100075-650 |
R5.0 |
10 |
20 |
75 |
2 |
|
BNM12120075-650 |
R6.0 |
12 |
24 |
75 |
2 |
|
BNM14140100-650 |
R7.0 |
14 |
30 |
100 |
2 |
|
BNM16160100-650 |
R8.0 |
16 |
30 |
100 |
2 |
|
BNM18180100-650 |
R9.0 |
18 |
30 |
100 |
2 |
|
BNM20200100-650 |
R10.0 |
20 |
30 |
100 |
2 |
|
BNM22220100-650 |
R11.0 |
22 |
30 |
100 |
2 |
|
BNM25250100-650 |
R12.5 |
25 |
30 |
100 |
2 |
Specifications:
|
Part Number |
Dia/mm |
Shank/mm |
Flute Length/mm |
Overall Length/mm |
Flute |
|
EM04010050-650 |
1.0 |
4 |
3 |
50 |
2/4 |
|
EM04015050-650 |
1.5 |
4 |
4 |
50 |
2/4 |
|
EM04020050-650 |
2.0 |
4 |
6 |
50 |
2/4 |
|
EM04025050-650 |
2.5 |
4 |
7 |
50 |
2/4 |
|
EM04030050-650 |
3.0 |
4 |
8 |
50 |
2/4 |
|
EM03030050-650 |
3.0 |
3 |
8 |
50 |
2/4 |
|
EM04040050-650 |
4.0 |
4 |
11 |
50 |
2/4 |
|
EM06050050-650 |
5.0 |
6 |
13 |
50 |
2/4 |
|
EM05050050-650 |
5.0 |
5 |
13 |
50 |
2/4 |
|
EM06060050-650 |
6.0 |
6 |
15 |
50 |
2/4 |
|
EM08080060-650 |
8.0 |
8 |
20 |
60 |
2/4 |
|
EM10100075-650 |
10.0 |
10 |
25 |
75 |
2/4 |
|
EM12120075-650 |
12.0 |
12 |
30 |
75 |
2/4 |
|
EM14140100-650 |
14.0 |
14 |
45 |
100 |
2/4 |
|
EM16160100-650 |
16.0 |
16 |
45 |
100 |
2/4 |
|
EM18180100-650 |
18.0 |
18 |
45 |
100 |
2/4 |
|
EM20200100-650 |
20.0 |
20 |
45 |
100 |
2/4 |
|
EM22220100-650 |
22.0 |
22 |
45 |
100 |
2/4 |
|
EM25250100-650 |
25.0 |
25 |
45 |
100 |
2/4 |
